Supo (Xiamen) Intelligent Equipment Co.,Ltd
One Stop for Lithium Battery Pack Production Line
Add to Cart
Automatic Battery Sorting Machine 18650 Battery Grading Sorting Machine 10 grades
Used for battery cell voltage and resistance testing and sorting 5000pcs/Hrs
Feature
A. Latest hopper type automatic feeding structure to ensure stable feeding and no impact and scratch on the battery, suitable for continuous production.
B. High precision and stability internal resistance tester
C. less than 1 second loading and unloading time.
D. 10 storage structure with full alarm function.
E. Automatically IR and Voltage data analysis
Specification:
| Equipment efficiency | 60 ~ 70PPM |
| Equipment mobile rate: | more than 95% |
| IR Accuracy | +/-0.5% RDG, display resolution 0.01 milliohm; |
| Voltage Accuracy: | +/-0.05% RDG, display resolution: 0.1 MV; |
| IR Error | < 1 milliohm (AC resistance test) |
| Voltage Repeatable error | < 1 MV |
| Equipment Dimension | L*W*H=1450*670*1650mm |
| Air Pressure | 0.6Mpa |
| Input power: | AC220V/50HZ 1KW |
Key Components:
| Tester | precision voltage internal resistance tester HK3561 |
| Computer | IPC |
| PLC | Panasonic FP-X series |
| Servo | Panasonic A5 series |
| Sensors | Panasonic and OMRON |
| Guide | Taiwan Hiwin |
| Bearings | Japan NSK |
| Cylinder | Airtac |
| Switching power supply | Taiwan Meanwell |
